A wooden door is a door made primarily of wood. It can be used for both exterior and interior applications and can be designed in a variety of styles.
Wooden windows are also a common feature in many homes and buildings, and are typically made from solid wood or engineered wood products such as plywood or MDF.
They can be designed to open in a variety of ways, including casement, double-hung, and sliding styles. Both wooden doors and windows can be painted or stained to match the aesthetic of the building they are installed in.
Image of wooden door and window detail and downloadable (in DWG) link below
Wooden door and windows detail drawing – 1
A wooden door and windows detail drawing is a technical drawing that provides detailed information about the construction and installation of a wooden door and window. It typically includes dimensions, profiles, materials, and other specifications necessary for the construction and installation of the door and window.
The drawing may also include information about hardware, such as hinges, locks, and handles, as well as any necessary clearance for the operation of the door and window.
Typically, it would include cross sectional, elevational, and plan views of the wooden door and window, with the necessary dimensions and specifications for the construction and installation of the door and window. It may also include information about the type of wood, finish, and any other specifications that are relevant to the construction and installation of the door and window.
The detail drawing is important for the manufacture, installation, and inspection of the wooden door and window. It’s also used as a reference for the maintenance and repair of the door and window.
Our tips to help you improve your architectural wooden door and window detailing.
